Santa Cruz Blur CC TR Frame

Santa Cruz Blur CC TR Frame
  • Color: Dark Matter and Salmon
  • Color: Sockeye Sal and Blue
Please select options
Sorry, this item is currently not available. Please contact us to check availability at sales.tbz@gmail.com or call us at (905) 232-1321.

Details

A fair advantage

Each weekend, at race venues the world over, there is one rider who gets hoisted upon the shoulders of the crowd and carried to the podium (or at least leaves with a water bottle as their prize). And, between each of those races, innumerable wannabes are putting in the hours on the rollers and in the gym, all because they want to feel what it's like to take the win. They know that, to beat the pack, every advantage needs to be acquired. That's where the Blur fits in.

We tapped into everything we've learned from years of making the highest quality carbon full-suspension bikes so that we could put as little (weight) as possible into the Blur frame. The trim frame and super-efficient Superlight suspension will be the key to translating your input into competition-beating performances.

But, the Blur isn't just for the short track. Two water bottle mounts within the front triangle should keep chuggers happy. And, the high quality fit, finish, and carbon construction promises multi-day racers a worry-free existence, meaning there's no fiddly proprietary parts that could leave you stranded in a Cape Epic or Breck Epic campsite. The carbon frame, while being light, is made to go the distance, and, as always, the legendary Santa Cruz lifetime warranty and Rider Support team have your back.

The Blur isn't guaranteed to make you a race winner, but being the lightest full-suspension carbon XC bike we've ever made at approx 23lb complete with a frame that is 289g lighter than the previous model, it might be the difference between claiming first place...or just crossing the line.

bike frame with labeled dimensions
Bike Sizes:
SMLXLXLXXL
A. Reach 412.3mm 437.8mm 457.5mm 482.5mm 488mm 513mm
B. Stack 587.4mm 597mm 606.5mm 620.7mm 639mm 657mm
C. Standover 743.5mm 746.4mm 745.4mm 750.1mm 698mm 698mm
D. Effective Top Tube 568.4mm 597.3mm 621.4mm 651.7mm 647mm 679mm
E. Head Tube Angle 67.1º 67.1º 67.1º 67.1º 65.5° 65.5°
F. Head Tube Length 90mm 100mm 110mm 125mm 140mm 160mm
G. Seat Tube Angle 75.1º 75º 74.9º 74.8º 76° 75.8°
H. Seat Tube Length 405mm 430mm 470mm 520mm 460mm 500mm
I. Bottom Bracket Height 339.9mm 339.7mm 339.6mm 339.4mm 332mm 332mm
J. Bottom Bracket Drop 32.6mm 32.8mm 32.9mm 33.1mm 41mm 41mm
M. Wheelbase 1125.8mm 1157mm 1183.2mm 1216.3mm 1239mm 1272mm
N. Front to Center 695mm 723.7mm 747.4mm 778mm 809mm 842mm
O. Chainstay Length 430.8mm 433.3mm 435.8mm 438.3mm 436mm 436mm

Specs

Frame Blur TR
Fork 100-120mm, 44mm offset
Rear Shock FOX Float Factory DPS
Wheels 29-inch
Axles 12x148mm
Tires 2.4-inch max
Bottom Bracket 73mm threaded
Chainrings 36t max
Front Derailleur No compatibility
Brakes 160 PM
Headset Integrated (IS41/52)
Seatpost 31.6mm

* Subject to change without notice.

Part Numbers

Option UPC MPN
Dark Matter and Salmon / Small 192219207063 68-22245-2-729-5899
Dark Matter and Salmon / Medium 192219207124 68-22245-3-729-5899
Dark Matter and Salmon / Large 192219207186 68-22245-4-729-5899
Dark Matter and Salmon / X-Large 192219207247 68-22245-5-729-5899
Sockeye Sal and Blue / Small 192219207094 68-22245-2-730-5899
Sockeye Sal and Blue / Medium 192219207155 68-22245-3-730-5899
Sockeye Sal and Blue / Large 192219207216 68-22245-4-730-5899
Sockeye Sal and Blue / X-Large 192219207278 68-22245-5-730-5899
