Details
Specs
Frame | 20.5" Top Tube Hi-Ten Steel |
---|---|
Fork | 20" 35mm Offset, Hi-Ten Steel |
Headset | 1 1/8” Integrated, Sealed, With 10mm Alloy Spacers |
Rims/Wheels | 20"x36Hx14G, Alloy Double wall Rims |
Front Hub | B3/8x100x165x36Hx14G, Semi-Sealed |
Rear Hub | 36Hx14G, With 3 pawls, Sealed bearings driven, 9T Driver |
Tires | K841 20"x2.25 |
Crankset | 170mm, CRMO BMX Crank, Tubular |
Sprocket | CW-1437, 25T Alloy Chainwheel |
Bottom Bracket | MID 19mm, Cromo 8T Spindle Axle |
Chain | Z1, 1/2x1/8x72L |
Handlebars | Alloy Rise: 8.5" Width: 28.5" 3° U/S, 11° B/S |
Grips | Legacy Bikes |
Stem | 28.6x22.2, Alloy 3D Forged BMX Stem |
Brake Levers | Alloy 2.5 Finger Brake Lever |
Brakes | Alloy U Brake |
Pedals | Plastic Pedal, 9/16 with 2 ball bearings |
Saddle | BMX Pivotal Saddle with PU inside |
Seat Post | Integrated |
Seat Clamp | Integrated seat clamp |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Red | 22LBSAVRED | 210000118420 |
Blue | 22LBSAVBLU | 210000118421 |
